HPS Hammond Power 225 KVA, 228128, HV 480V 2PH, LV 400V 3PH, Type K, Transformer

HPS Hammond Power 225 KVA, 228128, HV 480V 2PH, LV 400V 3PH, Type K, Transformer
$16,000 (USD)
or
Call 803.684.2410
Description
HPS Hammond Power 225 KVA, 228128, HV 480V 2PH, LV 400V 3PH, Type K, Transformer
225 KVA,
228128,
HV 480V 2PH,
LV 400V 3PH 324.7A
Type K, Transformer
Cooling ANN
NEMA-1
1500 lbs
Winding CU
imp 6.1
100HZ
Condition: New nos on pallet
Freight cost: Flat rate freight cost shown is approximant amount to a business address with a way to unload the pallet on the East coast, final cost will be sent after quote request. Please request a quote if you're out West, not a business or need a liftgate. Thank you. Fireside Surplus, Inc.
Payment: Due to value, wire transfer will be the only accepted payment method. We will provide details to buyer once the item is purchased. If you have any questions, feel free to message beforehand.
Free local pickup at Fireside Surplus in York S.C.
J(1) 1500# 3525
Specifications
| Manufacturer | Hammond |
| Model | 228128 |
| Condition | New |
| Stock Number | 306159136319 |
| Primary Voltage Rating (AC) | 480 V |
| Type | Power Transformer |
| Number of Phases | 3 |
| Secondary Voltage Rating (AC) | 400V |
| Maximum Operating Frequency | 100 Hz |
| Outlet Type | Type K |
| Secondary Current Rating | 324.7A |
